BEILOCKERY 110V Sewing Machine Needle Position Servo Brushless Motor Low Noise 1000W Split Type Electric Brushless Servo Motor 500-2500rpm for Light and Heavy-Duty Industrial Sewing Machine

Product Parameters:Voltage: AC110V 50/60HzPower: 1.3HP(1000W)Speed adjustment range: 500-2500rpmDiameter of external shaft of motor: 0.59"(15mm)Torque: 12N.mPackage size: 12.6"*11.4"*8.7"(32cm*29cm*22cm)Net weight/Gross weight: 13.4LB(6.1kg)/14.4LB(6.55kg)Item Included (056792)Sewing machine servo *1Pull rod *1Gasket *3Fixing screw *3Nut *3Flat pad *3Line buckle *3Self-tapping screw *3English manual *1Cushion *3

• Silent: The motor adopts a permanent magnet brushless design, fundamentally eliminating the noise and spark problems caused by traditional brushed motors due to brush wear, achieving an ultra quiet experience during operation
• Compact and portable: The compact body design, combined with a split structure, makes it easy to carry and move. In the case of limited sewing workspace, this small motor can easily adapt to ensure the smooth progress of sewing work
• Arbitrary speed regulation: This motor is driven by DC and has excellent speed regulation performance and stability. Through an advanced speed control system, users can easily achieve precise motor speed regulation to meet the needs of different speeds during the sewing process
• Split design: The split design allows for flexible separation and combination between the motor and the equipment body, facilitating the installation, maintenance, and upgrading of the equipment. This design not only improves the flexibility of the equipment, but also reduces maintenance costs and extends the service life of the equipment
• Energy saving: Motors can save up to 70% of electricity. 1.3HP, 1000 watt powerful heavy-duty electric servo motor, suitable for various types of industrial sewing machines, including straight sewing machines, overlock sewing machines, zigzag sewing machines, blind sewing machines, and heavy-duty indoor decoration machines
